DiGiGrid X-DG-D

DiGiGrid X-DG-D – compact 4-in / 4-out Ethernet audio interface featuring two high-quality mic preamps with +48V phantom power, two TRS line/instrument inputs (Hi-Z), real-time LED metering, headphone output, and analog gain control – perfect for studios, live setups, education, and networked audio systems on Mac and PC.

The DiGiGrid X-DG-D connects to your computer via a single Ethernet cable instead of USB, offering professional-grade performance and seamless integration into larger DiGiGrid systems. It can also function as a standalone audio interface. The unit features two XLR mic preamps with phantom power, low-cut filters, phase inversion, and monitoring switches. Two additional TRS line inputs provide 1 MΩ impedance, making them suitable for guitars and other Hi-Z sources.

All I/O (except for the headphone output, which is linked to the MON output) are fully independent. The MON output is volume-controlled, while the remaining TRS outputs are fixed-level. High-resolution LED meters allow precise monitoring of all inputs and outputs. With robust build quality and intuitive operation, the X-DG-D is ideal for professional recording, educational environments, and live sound configurations. It delivers low-latency audio at up to 96 kHz via a single Cat 5e or Cat 6 Ethernet cable.

KEY FEATURES

• 4-in / 4-out Ethernet audio interface
• 2 XLR mic preamps with +48V phantom power, low-cut filter, phase invert, and monitor
• 2 TRS Hi-Z inputs for instruments or line-level signals
• 4 TRS line outputs (one MON output with volume control)
• Headphone output linked to MON out
• Supports up to 96 kHz sample rate
• High-resolution LED metering for inputs and outputs
• Functions standalone or as part of a DiGiGrid network system
• Analog control for transparent signal path
• Ideal for live sound, home studios, education, and pro studios
• Single-cable Ethernet connection (Cat 5e / Cat 6)

TECHNICAL SPECIFICATIONS

• Inputs: 4 total (2 x XLR, 2 x 1/4" Jack TRS)
• Outputs: 4 x 1/4" Jack TRS
• Headphone output: 1 x TRS (linked to MON out)
• Sample rate: 96 kHz
• Bit depth: 16-bit
• Phantom power: +48V
• Connection type: Ethernet (Cat 5e / Cat 6)
• ASIO support: Yes
• ADAT support: No
• Color: Blue
• Dimensions: 220.5 x 160 x 78.5 mm
• Weight: 1.7 kg
• Compatibility: macOS / Windows
• Manufacturer origin: United Kingdom
