Wolff Audio MeMore RJ45 RAT

Wolff Audio MeMore RJ45 RAT Adapter Card – an expansion card for the MeMore personal monitor mixer that enables integration with analog-over-Ethernet audio distribution systems.

The RJ45 RAT adapter card allows you to replace bulky and heavy analog multicore snakes with lightweight and inexpensive CAT5/CAT6 network cabling. It is specifically designed for the Wolff Audio MeMore personal monitor mixer and is fully compatible with the Rat Sound RATCAT system. With this card, the full 12 audio channels of the MeMore mixer can be transmitted using just three Ethernet cables.

The adapter features four RJ45 connectors. Three of them are used to transmit 12 audio channels (4 per cable), while a fourth, dedicated connector handles bidirectional talkback communication (the "HearMe" feature) between linked MeMore units. The card also includes parallel RJ45 outputs and DB25 connectors, making it easy to daisy-chain multiple units into a larger system with minimal cabling.

KEY FEATURES

• Analog over Ethernet: Replaces analog multicore snakes with standard CAT5/CAT6 cabling.
• 12 Channels via 3 Cables: Full 12-channel audio support for the MeMore mixer using three network cables.
• Bidirectional Talkback: Dedicated fourth RJ45 connector for the HearMe function.
• Compatibility: Fully compatible with the Rat Sound RATCAT audio distribution system.
• Easy Expansion: Parallel outputs allow for simple daisy-chaining of multiple MeMore mixers.
• Simple Installation: The card installs directly into the MeMore mixer.

TECHNICAL SPECIFICATIONS

• Application: Wolff Audio MeMore Personal Monitor Mixer
• Connectors: 4x RJ45 (3x Audio, 1x HearMe), 2x DB25 (Thru), 4x RJ45 (Thru)
• Channel Configuration: 12 audio channels (4 per cable) + bidirectional Talkback
• Cable Compatibility: CAT5 / CAT6
• System: Compatible with Rat Sound RATCAT
• Package Contents: Wolff Audio MeMore RJ45 RAT Adapter Card
