Prism Sound Lyra 2 is a reference-grade USB audio interface that combines exceptional analog-to-digital and digital-to-analog conversion with a compact design, making it ideal for both studio and mobile applications. Offering up to 24-bit/192 kHz resolution, the Lyra 2 delivers outstanding clarity and precision, meeting the demands of the most discerning audio professionals.
KEY FEATURES OF PRISM SOUND LYRA 2
- High-Quality AD/DA Conversion: The Lyra 2 utilizes Prism Sound's renowned converters, ensuring transparent and accurate audio reproduction.
- Two Class-A Microphone Preamplifiers: These preamps provide clean and detailed recordings, faithfully capturing the original sound source.
- Front-Panel Hi-Z Inputs: Two 1/4" instrument inputs allow direct connection of guitars and other high-impedance instruments.
- Soft-Clip Limiting (Overkiller): The analog input channels feature a switchable 'Overkiller' circuit that gently absorbs transients, allowing signal levels to be pushed without risk of distortion.
- Flexible Digital Connectivity: The Lyra 2 offers S/PDIF and ADAT inputs and outputs, facilitating integration with various digital devices.
- Built-In DSP Mixer: Enables low-latency monitoring and the creation of custom mixes for each output, essential for recording and live performances.
- Stable Clocking: An advanced clock circuit with hybrid dual-stage DPLL minimizes jitter, ensuring the highest audio quality.
- Intuitive Control Panel: The Lyra control software allows easy management of settings and real-time parameter monitoring.
- Compact and Robust Design: Ideal for both mobile and studio use, offering durability and reliability in various environments.
TECHNICAL SPECIFICATIONS OF PRISM SOUND LYRA 2
- Resolution: Up to 24-bit/192 kHz
-
Analog Inputs:
- 2 x XLR with 48V phantom power and -20 dB pad
- 2 x 1/4" TRS (balanced or unbalanced)
- 2 x 1/4" TS Hi-Z on the front panel
-
Analog Outputs:
- 4 x 1/4" TRS (balanced or unbalanced)
- 1 x 1/4" TRS headphone output with independent volume control
-
Digital Inputs/Outputs:
- 1 x TOSLINK (S/PDIF or ADAT)
- 1 x RCA (S/PDIF or AES3 with included XLR adapter)
- Word Clock input/output on BNC connectors
- Interface: USB 2.0 (compatible with USB 3.0 and 3.1)
- Power Supply: Internal 90-250 VAC, 50/60 Hz
- Dimensions: 285 mm (W) x 242 mm (D) x 50 mm (H)
- Weight: 2.1 kg
