LEWITT LCT 40 Tr

LEWITT LCT 40 Tr — an 11-pin microphone cable with gold-plated XLR connectors, 5m in length, built for the LCT 840 and LCT 940 tube/FET combination microphones.

This cable is the essential link between the microphone capsule and its external tube power supply on the hybrid LCT 840 and LCT 940 designs, where signal, power, and polar-pattern control all travel over a single, multi-pin connector. Without the right 11-pin cable, the complex tube-powering and pattern-switching system stays inaccessible — a standard 3-pin XLR mic cable can't carry that functionality.

One Connection for Signal, Power, and Mode Control

Hybrid tube/FET microphones need to carry more than just an audio signal — the tube power supply also has to deliver heater and plate voltage to the tube, and receive polar-pattern switching commands from a remote control panel. LCT 40 Tr solves this with an 11-pin XLR connector that bundles all these functions into one dedicated cable, removing the need to run several separate cables between the capsule and the power supply.

Stable Transmission Without Quality Loss Over 5 Meters

In a typical setup with the tube microphone in a vocal booth, away from the power supply sitting in the control room, conductor resistance and shielding quality determine how clean the signal arrives at the tube preamp and how stable the tube's supply voltages remain. The cable's oxygen-free copper (OFC) construction with low resistance minimizes signal loss across the full 5-meter run, preserving the microphone's tonal character without added noise from substandard wiring.

KEY FEATURES

• 11-pin XLR cable dedicated to the LCT 840 and LCT 940 microphones
• 5m length
• Gold-plated XLR connectors (female/male on opposite ends)
• Oxygen-free copper (OFC) construction, low resistance
• Simultaneously carries audio signal, tube power, and mode control
• Identical to the cable factory-bundled with the microphone set
• Designed exclusively for use with the LCT 840 / LCT 940 microphones

TECHNICAL SPECIFICATIONS

• Connector type: 11-pin XLR (male/female on opposite ends)
• Length: 5m
• Conductor material: oxygen-free copper (OFC)
• Connector finish: gold-plated
• Compatibility: Lewitt LCT 840 and LCT 940 microphones
