Burl Audio B80-BAD4M-1414

Burl Audio

Burl Audio B80-BAD4M-1414

Sale price€2.422,00

Tax included. Shipping calculated at checkout

No reviews
No reviews
SKU: 21897
Quantity:
Delivery within 8-12 weeks

Contact

Burl Audio B80-BAD4M-1414 – a modular B80 Mothership converter platform configuration fitted with the mastering-grade BAD4M ADC card. The system is built on the B80 Mothership chassis, with ten slots for 4- or 8-channel conversion cards, letting the interface scale up to 80 analog channels depending on installed cards and the swappable motherboard responsible for the digital protocol - Dante, MADI, SoundGrid, or a direct Pro Tools connection. The BAD4M card adds four channels of mastering-grade analog-to-digital conversion with a 10 Hz to 30 kHz frequency response (±0.1 dB) at 96 kHz, a 115 dB dynamic range, and THD+N of -96 dB at +22 dBu full scale.

A choice between transformer and transformerless paths on one card

The BAD4M lets you switch the input analog stage between a classic BX1 transformer path, coupled without op-amps, and a newer transformerless BOPA14 preamp built as a fully discrete Class-A design. That flexibility removes the need for two separate conversion cards for sessions that call for analog saturation versus mastering work, where maximum transparency in the signal path matters - a switch on the card does the job instead of swapping hardware mid-session.

Modular channel expansion without replacing the whole interface

Ten independent card slots in the Mothership chassis let you add conversion channels gradually as a studio's needs grow, without buying a new interface every time the recording system expands. The swappable motherboard allows a change of digital transmission protocol - for example, moving from a direct Pro Tools connection to a Dante network - without touching the analog path of conversion cards already installed in the chassis.

KEY FEATURES

  • B80 Mothership chassis with ten conversion card slots, up to 80 channels
  • Swappable motherboard: Pro Tools (Digilink), MADI, Dante, or SoundGrid
  • BAD4M card: 4 channels of mastering-grade ADC with XLR connectivity
  • Switchable input path: BX1 transformer or BOPA14 preamp
  • Stepped input attenuator in the B2 ADC style
  • Avid delay matching and a switchable ADC filter

TECHNICAL SPECIFICATIONS

  • System type: modular AD/DA interface, 4U chassis, up to 80 channels
  • Conversion card: BAD4M, 4-channel mastering-grade ADC
  • Frequency response: 10 Hz - 30 kHz (±0.1 dB at 96 kHz)
  • Dynamic range: 115 dB
  • THD+N: -96 dB at +22 dBu full scale
  • Analog path: discrete Class-A (BOPA14) or BX1 transformer-coupled
  • Card input connectors: 4 x XLR
  • Number of card slots in chassis: 10
