Audient EVO 16

Audient EVO 16 – 24-in/24-out USB Audio Interface with Smartgain, Motion UI, and Expandable I/O – 8 EVO mic preamps, advanced converters with 121dB dynamic range, Smartgain for all channels, dual headphone outputs, JFET instrument inputs, and ADAT/SPDIF expansion. Compatible with Mac, PC, and iOS.

The EVO 16 redefines the home and project studio experience with powerful hardware and intelligent features designed for modern creators. It includes 8 digitally-controlled EVO mic preamps for clean, accurate sound, Smartgain that automatically sets input levels for all channels, and a high-resolution Motion UI screen to simplify control and monitoring. With 24-in/24-out capabilities via ADAT/SPDIF, EVO 16 adapts easily to both small and large sessions.

On the front panel, two JFET instrument inputs recreate the feel of a tube amp front-end, while two high-headroom headphone outputs deliver enough power for high-impedance headphones. The interface features 8 line outputs for flexible routing to monitors, external FX, or cue mixes. Thanks to Audio Loop-back and Talkback functions, it’s ideal for content creators, streamers, and multi-source routing. Rugged steel housing, vibrant LED lighting, and rack-mount support ensure EVO 16 looks and performs like a studio centerpiece for years to come.

KEY FEATURES

• 24-in/24-out USB audio interface for Mac, PC, and iOS
• 8 EVO mic preamps with digitally controlled analog gain (up to 58 dB)
• Smartgain: automatic gain setting for up to 8 inputs simultaneously
• 121 dB dynamic range converters for ultra-clear audio
• Motion UI: high-resolution LCD with intelligent metering and channel control
• 2 JFET instrument inputs with classic amp feel
• 2 independent headphone outputs with support up to 600 Ohms
• 8 line outputs for monitor switching, outboard FX or cue mixes
• ADAT & SPDIF I/O – expand up to 16 additional channels
• Audio Loop-back for streaming and content creation
• Customizable front panel function buttons including ALT speaker switching and Mono
• Built-in Talkback functionality using any connected mic (USB or built-in)
• Metal chassis with non-slip rubber feet and optional rack-mount ears

TECHNICAL SPECIFICATIONS

• Mic gain range: 58 dB
• Line gain range: 58 dB (with -10 dB pad)
• Phantom power: 48V ±4V @ 10 mA/channel
• Mic EIN: < -127.5 dBu
• CMRR: > 80 dB @ 1 kHz
• Max input level: +16 dBu
• Mic input impedance: > 3 kΩ balanced
• Line input impedance: > 10 kΩ balanced
• Frequency response: ±0.5 dB from 10 Hz to 40 kHz
• Crosstalk: < -105 dBu @ 1 kHz, < -103 dBu @ 10 kHz
• THD+N @ 0 dBu (1 kHz): < 0.0015%
• SNR: 100 dB
• XLR wiring: Pin 2 = hot, Pin 3 = cold, Pin 1 = ground
• 1/4" Jack: Tip = hot, Ring = cold, Sleeve = ground
