Arturia AudioFuse 16Rig

• Combines connectivity with flexible configuration options
• To connect a full synth studio, complex live audio routing, DAW recording and more
• 24-bit / 96kHz
• 16 Analog input channels and 12 analog output channels
• Separate front stereo input (input 3/4) for connecting tablets, smartphones or synths
• Dual ADAT I/O ports with word clock synchronization
• Low Latency DSP Mixer
• Standalone audio and MIDI functionality
• Dedicated monitor volume control with mute and custom buttons to control studio monitors
• Custom buttons configurable (mono, dim or alternate speaker)
• Headphone volume control
• Reamp function
• Pad switch for all line inputs
• Colour display with rotary and push encoders
• 6 Direct Access buttons and Back/Home buttons for easy navigation
• USB hub functionality with front and rear USB ports for connecting peripherals
• Load and recall presets for quick setup (e.g. studio, live performance, streaming, etc.)
• Configurable for desktop or rackmount use
• Format: 19''/ 1U
• Dimensions (W x D x H): 440 x 45 x 260 mm
• Weight: approx. 4.5 kg
• Incl. AudioFuse Creative Suite
• Contents of the delivery: quick start guide, power cable, USB-C to USB-C cable, USB-C to USB-A cable, registration card as well as detachable rack ears for rack mounting

Analogue inputs

• 2 Mic / Line / Instrument combo inputs: XLR / 6.3 mm jack
• 16 Individually switchable line inputs (+4 dBu / -10 dBv): 6.3 mm TRS jack
• 1 Stereo line input: 3.5 mm jack

Analogue outputs:

• 8 DC-coupled line outputs: 6.3 mm TRS jack
• 2 Monitor outputs: 6.3 mm TRS jack - front mirrored: Output 3&4
• 1 Headphone output: 6.3 mm TRS jack
• 1 Headphone output: 3.5 mm jack

Digital inputs/outputs:

• Dual ADAT I/O for up to 16 channels I/O at 48 kHz: 2x input / 2x output
• Word Clock I/O: BNC
• 1 MIDI-In/Out/Thru: 5-pin DIN
• 1 MIDI Clock-Out: 3.5 mm jack
• 1 MIDI host USB port on the front for USB MIDI controllers
