The Violectric HPA V340 is a reference-grade headphone amplifier and professional line preamplifier built to serve as the backbone of analytical tracking and mastering environments. Engineered around a discrete, solid-state signal path, it delivers crystal-clear, distortion-free audio. This allows mixing engineers to verify their work with absolute confidence, unmasking intricate micro-details and transients without adding any artificial tonal coloration to the source material.
50V Operating Voltage and Massive Headroom
Driving notoriously inefficient planar magnetic drivers or high-impedance studio dynamics to their full potential is a hurdle for conventional amplifiers. The HPA V340 overcomes this by operating on a specialized 50 V internal voltage rail. This robust architecture enables the amplifier to effortlessly output up to 21 V RMS into a 600-Ohm load and push an immense 5000 mW into 50 Ohms. This high-voltage topology ensures that sudden dynamic peaks and fast transients are reproduced without clipping, while a high damping factor maintains strict mechanical control over the drivers for a tight, articulate low-end response.
Pre-Gain Staging and ALPS Accuracy
Accommodating both power-hungry open-back models and hyper-sensitive in-ear monitors (IEMs) on the same amp usually forces a compromise in the noise floor. Violectric solves this with a dedicated hardware Pre-Gain system on the rear panel, allowing engineers to manually adjust the circuit's sensitivity across 7 stages (from -18 dB to +18 dB). This adjustment secures a pitch-black background, completely devoid of audible hiss. Output attenuation is handled by a premium ALPS RK27 potentiometer, providing tactile, smooth adjustments and flawless left/right channel tracking—critical for accurately evaluating stereo width and panning.
KEY FEATURES
- Powerful 4-channel amplification stage delivering 5000 mW (50 Ohms) and 21 V RMS (600 Ohms) for demanding studio headphones.
- Exceptionally high 50 V internal operating voltage ensuring lightning-fast transient response and zero dynamic compression.
- Hardware Pre-Gain adjustment system (-18 to +18 dB) to optimize the noise floor for sensitive IEMs and low-efficiency planars.
- Premium ALPS RK27 volume potentiometer providing smooth attenuation and precise stereo channel tracking.
- Rugged aluminum chassis featuring a 6 mm thick front panel to shield the internal circuitry from electromagnetic interference.
TECHNICAL SPECIFICATIONS
- Device Type: Solid-state headphone amplifier / line preamplifier
- Analog Inputs: 2x Unbalanced RCA
- Line Outputs: 1x Balanced XLR, 1x Unbalanced RCA
- Headphone Outputs: 1x 4-pin XLR (Balanced), 2x 6.3 mm / 1/4" Jack (Unbalanced)
- Maximum Output Power: 5000 mW (at 50 Ohms)
- Maximum Output Voltage: 21 V RMS (at 600 Ohms)
- Volume Control: ALPS RK27 potentiometer
- Pre-Gain Adjustments: -18, -12, -6, 0, +6, +12, +18 dBr
- Frequency Response: 5 Hz – 250 kHz (-0.5 dB)
- Weight: 3.40 kg (7.5 lbs)
