LEWITT DTP 340 REX is a cardioid dynamic instrument microphone explicitly engineered to capture the massive low-end frequencies and heavy impact of kick drums and bass amplifier cabinets. Utilizing a large diaphragm and custom-tailored circuitry, it reliably translates both the sub-harmonic weight and the aggressive stick attack required to build a rock-solid rhythm section foundation in demanding studio sessions and live FOH applications.
Switchable Mix-Ready EQ at the Source
Mixing kick drums typically involves aggressive console equalization to carve out muddy mids and boost the fundamental lows and transient clicks. The DTP 340 REX addresses this physically via its integrated EFR (Enhanced Frequency Response) switch. In its linear setting, the microphone delivers an accurate, uncolored representation of the drum, suited for jazz or acoustic tracking. Engaging the "Enhanced" mode instantly applies a heavy mid-scoop while boosting sub-lows and upper-frequency attack, feeding a pre-contoured, mix-ready kick drum signal directly to the preamp.
Extreme SPL Handling and Secure Mounting
Placing a transducer inside a kick drum port exposes it to catastrophic sound pressure levels. The DTP 340 REX cleanly handles extreme SPLs without capsule saturation or mechanical distortion, keeping the critical low-end transient clean and punchy. Its uniform cardioid polar pattern heavily rejects off-axis cymbal and snare bleed. Furthermore, the microphone features an integrated stand adapter built directly into its heavy-duty die-cast zinc chassis, allowing for swift, slip-free angular positioning deep within the drum shell.
KEY FEATURES
- Large-diaphragm dynamic transducer strictly optimized for kick drums and bass instruments.
- Switchable EFR (Enhanced Frequency Response) provides an instant, pre-EQ'd punchy tone.
- Flawless handling of extreme sound pressure levels (SPL) without introducing clipping.
- Strict cardioid polar pattern effectively isolates the kick drum from stage and cymbal bleed.
- Integrated, adjustable stand mount eliminates the need for external clips and ensures stability.
- Rugged, heavy-weight die-cast zinc enclosure built to survive the rigors of touring.
TECHNICAL SPECIFICATIONS
- Acoustical operating principle: Dynamic (moving coil)
- Polar pattern: Cardioid
- Frequency range: 20 - 16,000 Hz
- Sensitivity: 1.04 mV/Pa, -59.6 dBV/Pa
- Internal impedance: 500 Ohms
- Connector: Gold-plated 3-pin XLR
- Microphone dimensions: 71 mm (diameter) x 158 mm (length)
- Net weight: 740 g
