Genelec 8020D White

Genelec 8020D White – compact active nearfield studio monitor with a 4-inch woofer.

The Genelec 8020D White is a professional reference monitor, ideal for mixing and mastering in smaller studios, broadcast vans, and home setups. Its bi-amplified design, featuring separate 50W Class D amplifiers for the woofer and tweeter, ensures precise and clean audio reproduction. Thanks to the patented Directivity Control Waveguide (DCW™) technology and the Minimum Diffraction Enclosure (MDE™), the monitor provides excellent stereo imaging and a flat, uncolored frequency response.

The monitor is equipped with the Intelligent Signal Sensing (ISS™) power-saving system, which automatically puts the unit into sleep mode after a period of inactivity. The included Iso-Pod™ stand isolates the monitor from its surface, reducing unwanted vibrations and allowing for precise tilt angle adjustment. Advanced protection circuitry safeguards the drivers from sudden signal peaks, ensuring reliability even in the most demanding production environments.

KEY FEATURES

• Bi-amplified design: dedicated 50W (LF) + 50W (HF) Class D amplifiers
• 4" (105 mm) woofer and 0.75" (19 mm) metal dome tweeter
• Directivity Control Waveguide (DCW™) technology for controlled dispersion
• Minimum Diffraction Enclosure (MDE™) made from die-cast aluminum
• Intelligent Signal Sensing (ISS™) power-saving system
• Iso-Pod™ isolation stand included for vibration reduction and angle adjustment
• Room Response Compensation switches for acoustic tuning
• Advanced protection circuitry against overload
• Versatile mounting options

TECHNICAL SPECIFICATIONS

• Frequency Response: 56 Hz – 25 kHz (-6 dB)
• Frequency Response Accuracy: ± 2.5 dB (62 Hz – 20 kHz)
• Maximum SPL: 100 dB
• Amplifier Power: 50 W (LF) + 50 W (HF)
• Drivers: Woofer 105 mm (4"), Tweeter 19 mm (3/4")
• Inputs: 1 × Analog XLR (balanced)
• Dimensions: 242 × 148 × 142 mm (9 5/8" × 5 13/16" × 5 5/8") with Iso-Pod
• Weight: 3.2 kg (7.1 lbs)
• Enclosure Material: Die-cast aluminum
• Color: Matte White (indicated by DWM)
