The Ex Machina Ganymede is a premium active three-way studio monitor tailored for critical nearfield listening in professional mixing and mastering rooms where space is at a premium. By inheriting the uncompromising core technologies of the larger flagship systems, the Ganymede delivers ruthless phase coherence and exceptional transient response within a highly compact footprint. It acts as an acoustic microscope, bridging cutting-edge materials science with rigorous DSP optimization to ensure flawless translation.
Surgical Phase Linearity via Advanced DSP
Conventional multi-way monitors struggle with transient smearing and group delay at crossover points, leading to a loss of depth and impact. The Ganymede obliterates these issues by leveraging a 5th-generation SHARC+ DSP paired with flagship AKM Velvet Sound AD/DA converters. This powerful architecture calculates real-time digital crossovers, ensuring an incredibly tight ±15° phase tolerance across the entire frequency spectrum. The resulting sonic image grants audio engineers surgical accuracy when panning elements, guaranteeing that dynamic hits like kick drums and snares retain their authentic, time-aligned punch.
Point-Source Focus and Articulate Low End
At the physical heart of the system is a custom 5.5-inch coaxial driver employing advanced composite Metamodal TX carbon fiber diaphragms. This configuration dictates a true point-source radiation with a perfectly symmetrical dispersion pattern, eliminating off-axis comb filtering. Low frequencies are managed by a dedicated 7-inch woofer housed in a sealed, acoustically inert Valchromat cabinet. Powered by high-headroom Hypex Ncore amplifiers, this sealed-box approach strictly avoids the port turbulence and “ringing” associated with bass-reflex designs, yielding tight, fast, and articulate lows extending linearly down to 45 Hz.
KEY FEATURES
- Compact three-way nearfield architecture boasting flawless amplitude and phase coherence.
- Custom 5.5-inch coaxial midrange/tweeter featuring aerospace-grade, resonance-canceling Metamodal TX carbon diaphragms.
- High-excursion 7-inch low-frequency driver housed in a sealed, heavily damped Valchromat enclosure.
- Onboard 5th-Gen SHARC+ DSP executing phase-linear digital crossovers for a strict ±15° phase response.
- Flagship AKM Velvet Sound converters paired with transparent, ultra-fast Hypex Ncore amplification.
TECHNICAL SPECIFICATIONS
- Design: Active 3-way, sealed enclosure nearfield monitor.
- Drivers: 7" low-frequency driver, 5.5" coaxial mid/high transducer (with 1" tweeter).
- Frequency Response: 45 Hz – 30 kHz (±1 dB).
- Phase Linearity: ±15° tolerance across the usable spectrum.
- Amplification: Tri-amplified via discrete Hypex Ncore modules.
- DSP & Conversion: 5th-Gen SHARC+ processor with AKM Velvet Sound AD/DA.
