Studiologic Numa Compact SE

The Studiologic Numa Compact SE is a compact digital piano featuring an 88-key semi-weighted keyboard, 200-voice polyphony, 148 sounds, and 4 dedicated sound engines. It is equipped with 2 full-range built-in speakers, and its sound processor supports up to 6 simultaneous effects.

The Acoustic Engine delivers realistic acoustic piano tones using physical modeling technology. All samples are recorded in a professional studio, are high-resolution, and layered to reproduce the most authentic sound of each note. In addition, the Electric Engine faithfully reproduces the sound of electric pianos with stunning accuracy.

The organ section is implemented in a separate sound engine. With the Organ Engine, you can create the right tone for gospel, jazz, or church music, as well as powerful rock music. The Synth Engine provides a versatile synthesizer for creating your unique sound – perfect for electronic music!

You can enhance your playing experience on each sound engine with 2 programmable joysticks, as well as the Aftertouch function. Convenient buttons, knobs, a clear OLED display, and the effects processor help you with this.

The Numa Compact SE features an acoustic system for quick practice sessions, at home, or for small gigs. For larger stages, it is equipped with audio outputs that can be used to connect to a keyboard combo amp or a mixer.

You must know about Numa Manager App. It's help to transfer new sounds and choose their positions. You can free download it and easy update the firmware and organize the Programs.

Numa Compact SE Features

• Powerlfull Acoustic, Organ, Synth, Electric Engine
• Max Polyphony 200
• Semi-weighted keyboard
• Built-in speakers
• True Sound Stereo multi-samples
• Over 100+ Sounds
• Real-time control with 9 Drawbars
• FX processor
• Numa Manager desktop app
• USB Audio.

Numa Compact SE Specs

Keyboard

• 88 Keys, Ivory look, TP/9 PIANO semi-weighted Action
• Dual switch detection system
• Aftertouch
• Touch: Soft, Medium, Hard, Fixed (programmable).

Sound generation

• 148 Factory Sounds: 12 Acoustic Piano, 12 Electric Piano, 12 Keyboards, 16 Bass & Guitars, 24 Organs, 40 Synthesizers, 16 Orchestral, 16 Other sounds
• Max Polyphony 200 voices
• TrS (True Sound) Stereo multi-samples
• Additional downloadable sounds
• Acoustic Engine: Strings and Duplex Resonance, Damper noise, Hammer noise
• Electric Engine: Tine dedicated controls, Tine sounds for EP, Wurly and FM emulations, Damper noise
• Organ Engine: Integrated tone wheel organ model
• Synth Engine: Integrated waveform generator.

Effects / Processing

• Up to 6 effects simultaneously: 2 FX on Lower + 2 FX on Upper + Reverb + Strings resonance
• Dedicated effects for acoustic piano, electric piano, organ and synth sounds
• FX1: Drive, Chorus, Phaser, Flanger
• FX2: Rotary, Tremolo, Pan Trem, Delay
• REVERB: Room, Hall, Plate, Spring.

Features

• Sound and Programs: 120 User programs, 1 GB Samples memory
• 6 Sections: 2 Sounds in Layer or Split mode, 2 Sounds (additional) from MIDI/USB, 2 MIDI Zones in Layer or Split mode
• Edit functions: Global, Program, Part, Mixer (Lower / Upper / Zone A / Zone B volume control)
• Master controls: Bass, Treble, Mastering, Volume
• MIDI: 2 Programmable Zones - A/B, Program Change, Bank Select (LSB, MSB), MIDI Channel, Volume, Split assign, Transpose, Octave. Pedals 1-2 assign, Sticks 1-2 assign.

Speaker system

• 10 + 10W built-in digital Amplifier
• 2 Elliptical full range speakers.

Controls / UI

• OLED display 128 x 64 dots
• Encoder with push function
• 7 potentiometer
• 23 buttons
• Stick 1: Pitch
• Stick 2: Mod + FX Control.

Connections

• Audio OUT: 2x 6,3 mm mono jack (L+R)
• Headphones: 6,3 mm TRS jack (programmable as Aux out)
• Pedals: Expression, Universal
• MIDI: In, Out
• USB: Audio, MIDI, power2, Numa Manager.

Power supply

• DC IN: 12V
• Adapter: Input: 100-240V / Output: 12V-2,5A.

Size and weight

• Width: 127 cm / 50"
• Depth: 23 cm / 9"
• Height: 10 cm / 4"
• Weight: 7,1 Kg / 15,6 lbs.

Package content

• Numa Compact SE / Numa Compact X SE
• USB cable
• Power adapter.
