EVE AUDIO EXO 25 - 2-Way Studio Monitor
Optionen wählen
EVE Audio EXO 25 is a compact 2-way nearfield studio monitor designed for professionals who demand uncompromising precision in a small footprint. At its core lies a 5-inch woofer with a CAL (Coated Aluminium) diaphragm, delivering fast transient response and surprising bass depth down to 44 Hz. It is paired with the newly developed Precision AirMotion Transformer (PAMT) tweeter housed in a GDC (Guided Directivity Control) waveguide, ensuring a wide sweet spot, excellent linearity, and pristine high frequencies up to 24 kHz.
The advanced electronics of the EXO 25 rely on a powerful DSP engine and high-resolution A/D converters driving two amplifiers with 140 W each (280 W total), allowing for a maximum SPL of 116 dB (half-space). Intuitive operation is provided by a rear OLED display and SMART knob, enabling precise calibration of filters (High-Shelf, Mid EQ, Desk Filter, Low-Shelf) and volume. The aerodynamic LDE (Low Diffraction Enclosure) with rounded edges minimizes diffraction, while rear bass-reflex ports reduce air turbulence noise.
KEY FEATURES
- 2-way active studio monitor with DSP
- New Precision AirMotion Tweeter (PAMT) with GDC waveguide
- 5-inch woofer with CAL (Coated Aluminium) diaphragm
- Class D amplifiers with 280 W total power (140 W woofer + 140 W tweeter)
- Advanced DSP engine with OLED display and SMART encoder
- LDE (Low Diffraction Enclosure) with rounded edges
- Extensive acoustic calibration options (4 EQ filters)
- Analog (XLR, RCA) and Digital (S/PDIF with Thru) inputs
- M6 mounting threads on the bottom
TECHNICAL SPECIFICATIONS
- Frequency Range: 44 Hz – 24 kHz (-3 dB)
- Max SPL: 116 dB (half space > 100 Hz)
- Woofer: 130 mm (5") CAL
- Tweeter: Precision AirMotion Transformer (PAMT)
- Crossover Frequency: 2200 Hz
- Output Power: 140 W (Low) + 140 W (High)
- Inputs: XLR (10k), RCA (10k), S/PDIF (RCA)
- Filters: High-Shelf (>3kHz), Mid EQ (3.2kHz), Desk Filter (550Hz), Low-Shelf (<300Hz)
- A/D Converters: 24-bit/192kHz
- Dimensions: 175 x 285 x 225 mm
- Weight: 5.9 kg
- Power Supply: 100-240V AC
