The ATC SCM20PSL PRO MK2 (PASSIVE) is a compact, passive, 2-way studio monitor designed for professional audio environments. It features the same ATC-built woofer and tweeter as the acclaimed ATC SCM20PSL PRO MK2 (PASSIVE), ensuring unmatched audio fidelity and precision. The low-frequency driver incorporates a 150mm bass cone paired with a 75mm soft dome, delivering exceptional clarity in the midrange. The ferrofluid-free tweeter ensures durability and consistent performance for a lifetime of use.
A standout feature of the ATC SCM20PSL PRO MK2 (PASSIVE) is its tri-wire connection panel, allowing independent amplification of low, mid, and high-frequency drivers. Renowned for their high build quality, ATC monitors are trusted by top studios worldwide, and the ATC SCM20PSL PRO MK2 (PASSIVE) is no exception.
Key Features of the ATC SCM20PSL PRO MK2 (PASSIVE)
- High-quality drivers: 150mm Super Linear woofer with a 75mm voice coil, and a 25mm dual-suspension soft dome tweeter.
- Extended frequency response: 80Hz to 20kHz with excellent amplitude linearity.
- Tri-wireable design: Separate inputs for bass, midrange, and treble frequencies for enhanced control.
- Compact and robust design: Ideal for professional monitoring in tight spaces.
- Trusted brand: Used in leading studios worldwide for critical mixing and mastering.
Specifications of ATC SCM20PSL PRO MK2 (PASSIVE)
- Low-Frequency Driver (LF): 6.5”/150mm Super Linear with 75mm/3" voice coil.
- High-Frequency Driver (HF): 1”/25mm dual suspension Soft Dome.
- Frequency Range: 80Hz - 20kHz (+/-2dB).
- Cut-off Frequencies: 55Hz - 25kHz (-6dB freestanding).
- Dispersion: Horizontal +/-80°, Vertical +/-10°.
- Maximum SPL: 108dB (per pair @ 1m).
- Crossover Frequency: 2.1kHz.
- Recommended Amplifier Power: 75 to 300 Watts.
- Nominal Impedance: 8 Ohms.
- Connectors: 2 x pairs of binding posts (bi-wireable).
- Dimensions (HxWxD): 450 x 250 x 294mm.
- Weight: 18kg (per cabinet).
