Shure Axient AD4DE-A Dual Receiver (470-636 MHz) – dual-channel digital wireless receiver with Quadversity technology, designed for professional live and broadcast applications. Provides reliable transmission up to 300 feet, supporting up to 47 simultaneous channels with advanced RF spectrum management. Ideal for stages, studios, and high-demand events. Compact rackmount enclosure (483 x 44 x 271 mm, 2.8 kg) with color display and Ethernet networking.
AD4DE-A features AES3 and analog I/O, 24-bit/48 kHz conversion. Functions: ShowLink for remote transmitter control, Networking for frequency coordination, Diversity with 4 antennas for stability. Supports up to 2 transmitters, automatic switching, RF monitoring. Redundant power, compatible with ADX transmitters.
As part of Axient Digital series, delivers crystal-clear sound without dropouts, ready for mission-critical use without compromise.
MAIN FEATURES
- Dual-channel receiver with Quadversity (4 antennas) for 300 ft range
- Frequency: A-band 470-636 MHz, up to 47 channels
- ShowLink: remote transmitter control via RF
- Networking: Ethernet for frequency coordination
- Inputs/Outputs: 2x XLR analog, 2x AES3, Dante optional
- Color display with RF/audio metering
- Redundant power, automatic switching
- 1U rackmount, portable with ears
TECHNICAL SPECIFICATIONS
- Frequency: 470-636 MHz (A-band)
- Channels: Up to 47 simultaneous
- RF Range: Up to 100 m (300 feet)
- A/D Conversion: 24-bit/48 kHz
- Inputs: 2x XLR female (mic/line), BNC RF
- Outputs: 2x XLR male (line), AES3 XLR, Ethernet RJ45
- Frequency Response: 20 Hz–20 kHz
- Dynamic Range: 120 dB (A-weighted)
- THD + N: < 0.002% @ 1 kHz
- Power Supply: 100-240 V AC, redundant
- Dimensions (H × W × D): 44 x 483 x 271 mm
- Weight: 2.8 kg
- Included: AD4DE-A, rack ears, BNC cables, power cord
- Product Code: SHU-AD4DE-A
