Elysia
Elysia museq
This item is available on a custom order basis only. Please contact us for more details. Contact us
Choose options
This item is available on a custom order basis only. Please contact us for more details. Contact us
This item is available on a custom order basis only. Please contact us for more details. Contact us
Elysia museq – musical analog equalizer for mastering/mixing, 5-band design for precise sound shaping. Offers clean, musical tone with Class A, discrete technology and boost/cut per band. Ideal for vocals, instruments, stereo mixes. 19" rack (483 x 88 x 237 mm, 5 kg) for 1U mounting.
museq uses 100% discrete Class A circuits with single transistors, custom 23-step pots, transformers for harmonics. LF band (9-200 Hz, shelf/cut ±15 dB), Bottom (18-400 Hz, peak ±15 dB, Q wide/narrow), Middle (150 Hz-3.5 kHz, peak ±15 dB, Q wide/narrow), Top (700 Hz-16 kHz, peak ±15 dB, Q wide/narrow), HF (1.8-35 kHz, shelf/cut ±15 dB). Warm option for slew rate limiter coloration.
As analog tribute, blends precision with musicality, ready for mastering without compromise.
MAIN FEATURES
- 5-band EQ with boost/cut per band
- 100% discrete Class A technology with transistors
- 23-step pots, matched stereo pairs
- Warm option for harmonic coloration
- Balanced XLR I/O
- Bypass and phase reverse switches
- 1U rackmount
- Hand-soldered
TECHNICAL SPECIFICATIONS
- Inputs/Outputs: Balanced XLR stereo
- LF Band: 9-200 Hz (shelf/cut ±15 dB)
- Bottom Band: 18-400 Hz (peak ±15 dB, Q 1.3/0.5)
- Middle Band: 150 Hz-3.5 kHz (peak ±15 dB, Q 1.3/0.5)
- Top Band: 700 Hz-16 kHz (peak ±15 dB, Q 1.3/0.5)
- HF Band: 1.8-35 kHz (shelf/cut ±15 dB)
- Frequency Response: 20 Hz–20 kHz (±0.5 dB)
- THD + N: < 0.005% @ 1 kHz
- Noise EIN: < -90 dBu
- Power Supply: 100-240 V AC
- Dimensions (W × H × D): 483 x 88 x 237 mm (1U)
- Weight: 5 kg
- Included: museq, manual
- Product Code: ELY-MUSEQ
