Lynx Studio Aurora (n) 24 To

Lynx Studio Technology AURORA(n) 24 TB is a 24-channel AD/DA converter with integrated Thunderbolt connectivity and an onboard microSD recorder. Designed for pristine signal integrity and unmatched transparency, it features 24-bit/192 kHz mastering-grade conversion, modular expandability, and future-proof digital architecture. The AURORA(n) is the next evolution of the iconic Aurora interface, ideal for top-tier studios requiring uncompromising audio fidelity.

KEY FEATURES

• 24-channel mastering-grade AD/DA conversion (24-bit / 192 kHz)
• Integrated Thunderbolt interface with ultra-low latency
• Built-in 32-channel microSD recorder for direct record/playback
• Modular expansion support for mic preamps, analog summing, AES3 + ADAT digital I/O
• Two audiophile-grade headphone outputs with independent volume control
• 1 in / 3 out Word Clock with second-gen SynchroLock 2™ technology
• Swappable LSlot cards for Thunderbolt, Dante, ProTools|HD, or USB
• Rugged 1U rackmount chassis with reinforced construction
• Ultra-transparent signal path with no added coloration or distortion
• Firmware updates for feature enhancements and long-term compatibility
• Used by Skywalker Sound, Dolby Labs, NPR, and Smithsonian for critical applications
• Compatible with Windows and macOS systems

TECHNICAL SPECIFICATIONS

• Line Inputs (AD conversion)
• THD+N: ‐113 dB @ 1 kHz, ‐1 dBFS, 20 kHz filter, +20 dBu trim
• Dynamic Range: 119 dB (A-weighted, ‐60 dBFS signal method)
• Frequency Response: ±0.010 dB, 20 Hz – 20 kHz
• Crosstalk: max ‐130 dB @ 1 kHz, ‐1 dBFS
• Common Mode Rejection: >80 dB
• Full-scale Trim Settings: +6 dBV, +20 dBu
• Line Outputs (DA conversion)
• THD+N: ‐108 dB @ 1 kHz, ‐1 dBFS, 20 kHz filter, +20 dBu trim
• Dynamic Range: 120 dB (A-weighted, ‐60 dBFS signal method)
• Frequency Response: ±0.025 dB, 20 Hz – 20 kHz
• Crosstalk: max ‐130 dB @ 1 kHz, ‐1 dBFS
• Full-scale Trim Settings: +6 dBV, +20 dBu
• Headphone Output (DA conversion)
• THD+N: ‐107 dB @ 1 kHz, ‐1 dBFS, 20 kHz filter, max volume
• Dynamic Range: 120 dB (A-weighted, ‐60 dBFS signal method)
• Frequency Response: ±0.025 dB, 20 Hz – 20 kHz
• Crosstalk: max ‐120 dB @ 1 kHz, ‐1 dBFS
• Max Output Level: 18.4 dBu
