Joranalogue Filter 8 is an advanced analog multimode filter module with incredible capabilities for Eurorack modular synthesizers. Filter 8 goes beyond a typical high-pass filter, combining signal generator functions, VCF, VCO, and much more in one device.
Filter 8 offers a new approach to signal generators and processors. It's not just a VCF - it's a versatile analog module capable of acting as a VCO, slope generator, multi-phase VCF, and more. A embodiment of flexibility and quality in a compact 12 HP form factor. A must-have module for serious modular synthesis systems.
Key features:
- 4-pole cascaded architecture based on classic op-amp topology
- Simultaneous outputs: 1-4 pole low-pass, 1 pole high-pass, phase shift, band-pass, notch
- Innovative resonance circuit without bass loss
- Self-oscillation mode: 8-phase sinusoidal VCO
- Temperature-stable, with level and nonlinearity compensation
- Range 2.8 Hz - 27 kHz for use as VCO, VCF, or shaper
- Simultaneous exponential and linear frequency modulation
- Hold mode for modulation freezing
- "Ping" input for percussive sounds
- Separate signal inputs for flexible patching
- Compensated outputs with dual-color indicators
- Precision-milled 2mm panel, premium components
