Antelope Audio Galaxy 64 Synergy Core — a 2U flagship audio interface designed for high-end studios, combining ultra-high channel count, premium AD/DA conversion, advanced clocking, and real-time Synergy Core DSP processing. With up to 64 analog I/O via DB25, Dante Audio-over-IP, Thunderbolt 3, HDX, and optical MADI all active simultaneously, Galaxy 64 delivers unmatched routing flexibility and audio quality.
The interface features Antelope’s 64-bit Acoustically Focused Clocking (AFC) technology and ultra-low-jitter management, delivering detailed stereo imaging and exceptional depth. With 12 DSP chips and 2 FPGA processors onboard, it supports up to 256 Synergy Core plugin instances in real-time — without burdening your host CPU. Four onboard stereo mixers provide extensive monitoring capabilities, while drag-and-drop virtual patchbay and network control streamline studio workflows. Galaxy 64 can operate standalone and be controlled remotely, making it a centerpiece for any professional setup.
KEY FEATURES
- 2U studio centerpiece with 64 analog inputs and 64 outputs via DB25
- Simultaneous Thunderbolt 3, Dante, Pro Tools HDX, and MADI I/O
- Up to 256 real-time DSP plugin instances powered by 12 DSP + 2 FPGA
- 36 Synergy Core effects included, modeled after rare studio hardware
- 64-bit AFC clocking technology for extreme precision and low jitter
- AD/DA conversion up to 192 kHz / 24-bit with 128 dB dynamic range
- Four stereo submixers with reverb, panning, and level control
- Drag-and-drop virtual patchbay with preset recall
- Standalone mode with full front-panel control
- Remote network control via second Thunderbolt 3 or LAN
TECHNICAL SPECIFICATIONS
- Analog Inputs: 8x DB25 (Tascam standard) — 64 channels at 24-bit / 192 kHz
- Analog Outputs: 8x DB25 (Tascam standard) — 64 channels at 24-bit / 192 kHz
- Monitor Outputs: 1x stereo pair TRS (balanced)
- Headphone Output: 1x 6.3 mm stereo jack
- Digital I/O: Dante (64ch @ 48 kHz), MADI optical (64ch @ 48 kHz),
- 4x HDX ports (128ch @ 192 kHz), Thunderbolt 3 (64ch @ 192 kHz)
- SPDIF I/O: 1x In, 1x Out (24-bit / 192 kHz)
- AES/EBU I/O: 1x In, 1x Out (24-bit / 192 kHz)
- Word Clock I/O: 1x In, 1x 10M In, 1x Loop Sync, 6x Out (BNC)
- Clocking: 64-bit AFC jitter-controlled master clock
- DSP Engine: 12 DSP chips + 2 FPGA processors
- Included Effects: 36 Synergy Core FX (EQ, compressors, mic pres, modulation, etc.)
- Virtual Mixers: 4 stereo mixers with 32 input channels each
- Standalone Operation: Yes
- Remote Control via Network: Yes
- Max Sample Rate: 192 kHz
- Bit Depth: 24-bit
- Bus Powered: No
- Power Supply: External PSU included
- Dimensions (W x D x H): 483 x 270 x 88 mm
- Weight: 6.4 kg
