Black Box Analog Design HG-2

Black Box Analog Design HG-2 – stereo tube harmonic processor adding warmth/depth to mixes, masters, sources. Uses Lundahl transformers, 12AX7/12AT7 tubes for even/odd harmonics, ideal for vocals, drums, guitars, buses. 2U enclosure (483 x 89 x 267 mm, 7.7 kg) with aluminum panels.

HG-2 features Pentode (odd harmonics)/Triode (even) sections, "Air" HF/"Thump" LF curves. Switches: Low Cut, Tilt EQ, Pentode/Triode blend. Balanced XLR I/O, low latency. Hand-soldered in USA for quality.

As analog tribute, adds musicality without compromise.

MAIN FEATURES

• Pentode/Triode sections for odd/even harmonics
• Air (HF)/Thump (LF) curves
• Tilt EQ, Low Cut filter
• Pentode/Triode blend, output trim
• Balanced XLR I/O
• 12AX7/12AT7 tubes, Lundahl transformers
• 2U rackmount
• Portable: 483 x 89 x 267 mm, 7.7 kg

TECHNICAL SPECIFICATIONS

• Tubes: 2x 12AX7, 2x 12AT7
• Transformers: Lundahl input/output
• Inputs/Outputs: Balanced XLR stereo, max +27 dBu
• Frequency Response: 20 Hz–20 kHz (±0.5 dB)
• THD + N: < 0.5% @ 1 kHz (with harmonics)
• Noise EIN: < -90 dBu
• Power Supply: 100-240 V AC
• Dimensions (W × H × D): 483 x 89 x 267 mm (2U)
• Weight: 7.7 kg
• Included: HG-2, manual
• Product Code: BBA-HG2
