AUDIENT ASP880 – 8-channel microphone preamplifier & ADC expander for audio interfaces. Features Audient Console mic pres with discrete Class-A design for ultra-low noise/distortion and analog warmth. Burr-Brown converters for high-fidelity capture. Ideal for expanding setups via ADAT for drums/bands.
8 mic/line inputs with variable impedance/HPF (25-250Hz), 8 insert points for outboard gear, 2 JFET DI inputs for instruments. Standalone ADC mode. All-metal 1RU rackmount with hand-milled knobs.
Enhances sessions with professional preamps and clean conversion.
MAIN FEATURES
- 8 Audient Console mic pres (60dB gain)
- Burr-Brown ADC converters
- Variable mic impedance/HPF
- 8 insert points pre-ADC
- 2 JFET DI inputs
- ADAT/AES/S/PDIF digital outputs
- Line inputs/outputs on DB25
- 48V phantom, pad, polarity reverse
- Standalone converter mode
- 3-year warranty, software bundle
TECHNICAL SPECIFICATIONS
- Inputs: 8 x XLR/TRS mic/line (balanced), 2 x 1/4" TS JFET DI
- Outputs: 8 x DB25 line (balanced), ADAT/AES/S/PDIF digital
- Mic Gain: -10 to +60dB (-10dB pad)
- Line Gain: -16 to +44dB (-10dB pad)
- Phantom Power: +48V @10mA/channel
- Mic EIN: <-127.5dBu
- Power Supply: Internal SMPS, 90-264V AC, fanless
- Dimensions (W x D x H): 19 x 7.4 x 1.75 in (1RU)
- Weight: Not specified
- Included: ASP880, power cord, software bundle
- Product Code: ASP880
