RME Digiface AVB- 256-channel AVB/USB 3.0 interface with support for up to128×128 @ 48 kHzIt seems you've only provided a comma without any text to translate. Could you please provide the Polish text you'd like translated into English?64×64 @ 96 kHzIt seems your message may have been cut off. Could you please provide more text or context that you'd like translated?32×32 @ 192 kHz, 1× Gigabit Ethernet AVB, with a 6.3 mm headphone output (DC-coupled),Word Clock I/O, with a mixerTotalMix FX(without FX DSP) and powered by USB bus.
Digiface AVBtransfers audio to/from the AVB network directly from the computer, offering up to 16 input and 16 output streams with configurable sizes (2–32 channels/stream). The included AVDECC controller detects AVB devices and establishes connections, andTotalMix FXprovides full routing and submixes to all outputs. ConnectorsWord ClockThey facilitate integration with existing infrastructure, and the headphone output 33/34 (DC-coupled) allows for direct monitoring.
The interface supports AVB/AVDECC (IEEE 1722/1722.1) and Milan mode, operates on USB 3.0 with very low latencies, and does not require an external power supply. Remote controlTotalMix Remote, compliance withARC USBand measuring toolsDIGICheckthey complete a professional set of features.
KEY FEATURES
- Total of 256 channels: 128 in/128 out @ 48 kHz; 64×64 @ 96 kHz; 32×32 @ 192 kHz
- AVB streams: up to 16 In + 16 Out; size 2–32 channels/stream (configurable)
- Gigabit Ethernet (RJ45, 100 Mb/s or 1 Gb/s; Auto MDI-X), AVDECC for establishing connections
- TotalMix FX – advanced routing and submixes (without DSP effects); support for TotalMix Remote
- Word Clock I/O (BNC; switchable termination 75 Ω), ARC USB compatible
- 6.3 mm headphone output (channels 33/34),DC-coupled, high-quality monitoring
- USB 3.0 power supply (bus-powered); compact housing for mobile and installation applications
TECHNICAL SPECIFICATION
- Network: 1× RJ45 (100 Mb/s / 1 Gb/s), for 16 AVB streams; AVDECC (IEEE 1722.1), Milan mode
- Channels / frequencies: do 128×128 @ 44.1/48 kHz; 64×64 @ 88.2/96 kHz; 32×32 @ 176.4/192 kHz
- Word Clock: In (BNC, 10 kΩ; 75 Ω termination enabled), Out (BNC, 5 Vss; 4 Vss at 75 Ω)
- Output Phones (33/34): 6.3 mm TRS, unbalanced; DR 110 dB RMS (113 dBA), THD+N −95 dB (0.0017%), imp. 2 Ω, level 0 dBFS/1 kΩ: +9.5 dBu; max power 50 mW; bandwidth up to 89 kHz @ 192 kHz
- Clock: Internal / AVB / Word; support for 44.1–192 kHz
- USB: USB 3.0, bus-powered; typical consumption 1.5 W (max 2 W)
- Dimensions / weight: 112 × 26 × 83 mm; 300 g
- Software: macOS/Windows drivers, RME AVB Controller (AVDECC), TotalMix FX, DIGICheck; TotalMix Remote
- WDM (Windows): 64 WDM channels (configurable in the driver)
