Antelope Audio Zen Quadro Synergy Core

Antelope Audio

Antelope Audio Zen Quadro Synergy Core

€538,54 €572,69
Save €34,15

Tax included. Shipping calculated at checkout

No reviews
No reviews
SKU: 54070
Quantity:
Pickup available at Warsaw Showroom

Antelope Audio Zen Quadro Synergy Core

Warsaw Showroom

Pickup available, usually ready in 24 hours

Nowogrodzka 6
102
00-513 Warszawa
Poland

+48573580840

Contact

Antelope Audio Zen Quadro Synergy Core is a high-end portable audio interface featuring four discrete console-grade preamps, dual USB-C connectivity, standalone operation with a color display, and real-time effects processing via the Synergy Core DSP+FPGA engine.

Designed for professional-grade conversion and versatility, Zen Quadro delivers up to 130 dB of dynamic range, clocked by Antelope’s proprietary 64-bit AFC technology, ensuring exceptional stereo imaging and crystal-clear detail during playback and recording. The interface includes four ultra-low-noise preamps with 6-transistor discrete topology and up to 75 dB of gain — perfect for dynamic and ribbon microphones without external boosters.

Its dual USB-C ports allow simultaneous use with two computers, or a computer and a mobile device, with full routing control and loopback functionality for streaming. The standalone mode, accessible via the color display, allows full control over routing, effects chains, and monitoring without a computer — ideal for live performance or hybrid stage setups. The second USB port also supports device charging.

The Synergy Core engine combines DSP and FPGA processing to model analog gear components in real time with virtually zero latency and no CPU load. Up to 48 mono effects can be applied simultaneously across 6 input channels, including compressors, EQs, modulation, amps, and cabs.

KEY FEATURES

  • 4 discrete console-grade preamps with 75 dB of gain
  • High-end AD/DA conversion with up to 130 dB dynamic range
  • Dual USB-C ports for simultaneous multi-device operation
  • Real-time Synergy Core FX processing with 37 included effects
  • Standalone mode with full routing and FX access via color display
  • 64-bit AFC clocking for ultra-precise synchronization
  • Loopback functionality for streaming setups
  • Modular synth-compatible DC-coupled I/O
  • Up to 192 kHz sample rate
  • Compatible with macOS and Windows
  • Supports up to 48 mono FX instances across 6 input paths
  • Robust metal chassis for durability

TECHNICAL SPECIFICATIONS

  • Connectivity: 2 × USB-C ports
  • Preamp gain: up to 75 dB
  • Dynamic range (conversion): up to 130 dB
  • Sample rate: up to 192 kHz
  • Effect processing: up to 48 mono instances
  • Loopback: supported
  • Standalone control via built-in color display
  • Dimensions: 210 × 136 × 58 mm
  • Weight: 0.9 kg
