Waves SOUNDGRID Titan-R Server is Waves’ flagship, ultra‑powerful SoundGrid DSP server, built to run hundreds of Waves plug‑ins in real time with ultra‑low latency down to about 0.8 ms at 44.1–96 kHz. It is designed for the most demanding live sound, broadcast and studio environments where maximum plug‑in power and rock‑solid reliability are crucial.
Titan-R is powered by an Intel Core i9 CPU and 16 GB of RAM, delivering roughly 30% more processing power than Extreme SoundGrid servers. The server features a full‑width 2U 19" rack chassis with built‑in rack ears and dual (redundant) power supplies, making it a perfect fit for critical shows and installations that cannot afford downtime.
With the Waves Titan-R SoundGrid Server, you can offload massive plug‑in loads from your host computer in systems built around eMotion LV1, SuperRack and other SoundGrid hosts. Titan-R works with any SoundGrid I/O and can also be used with standard ASIO/Core Audio interfaces via SoundGrid Connect, so integrating it into existing live or studio setups is straightforward. LED indicators for network and temperature status plus a quiet, optimized cooling design help ensure stable performance even under heavy DSP loads.
KEY FEATURES
- Waves’ most powerful SoundGrid DSP server for massive plug‑in sessions
- Approximately 30% more processing power than Extreme SoundGrid servers
- Ultra‑low latency, as low as about 0.8 ms at 44.1–96 kHz
- Intel Core i9 CPU with 16 GB RAM
- Dual, redundant power supply for maximum reliability in critical productions
- 2U 19" rackmount chassis with built‑in rack ears
- LED indicators for easy network and temperature monitoring
- Quiet, optimized fan design with minimal operating noise
- Reinforced RAM mounting for enhanced long‑term stability
- Use with any SoundGrid I/O, or with ASIO/Core Audio interfaces via SoundGrid Connect
- Ideal for large‑scale live sound, broadcast, houses of worship and high‑end studio setups
TECHNICAL SPECIFICATIONS
- CPU: Intel Core i9 (e.g. i9‑10900K or newer generation in current revisions)
- RAM: 16 GB
- Motherboard: Gigabyte professional‑grade board for audio applications
- Network: Intel controller (e.g. I225‑LM) with EtherCon/RJ45 port for SoundGrid networking
- Supported sample rates: 44.1, 48, 88.2, 96 kHz
- Typical system latency: around 0.8 ms (depending on SoundGrid configuration)
- Form factor: 2U, 19" rackmount
- Dimensions (W × H × D): approx. 482 × 88 × 392 mm
- Device weight: approx. 7 kg (15.4 lb)
- Power: dual redundant PSUs, 100–240 V AC, 50/60 Hz
- Typical power consumption: around 140 W
- Service ports: 2 × USB 3.0 (rear), 1 × HDMI (service/configuration)
- Operating temperature range: approx. 10–35 °C (max around 40 °C)
- Applications: touring rigs, live sound, broadcast, large permanent installations, top‑tier studios
