MOTU828x

MOTU 828x is a professional audio interface with Thunderbolt and USB connectivity, offering 28 inputs, 30 outputs, support for up to 192 kHz, two mic preamps, ADAT optical, S/PDIF, Word Clock, and a built-in CueMix FX digital mixer with DSP effects.

The 828x is one of MOTU’s best-selling and award-winning interfaces, now upgraded with next-gen connectivity and exceptional I/O flexibility. It features two high-quality mic/guitar inputs with +48V phantom power, eight balanced analog inputs and outputs via TRS jacks, XLR main outputs, dual ADAT ports (up to 16 channels), S/PDIF, MIDI, and Word Clock I/O. A direct signal path before A/D conversion allows outboard processing of mic channels, while the 828x’s hardware limiter offers up to 12 dB of headroom above digital zero. The CueMix FX mixer enables zero-latency monitoring, EQ, compression, and reverb—all without taxing your computer's CPU. The unit also functions in standalone mode, acting as a full-featured digital mixer. Its rugged metal chassis and full macOS/Windows compatibility make it a trusted centerpiece for any professional studio.

KEY FEATURES

• 28 inputs and 30 outputs of audio I/O
• Thunderbolt and USB 2.0 connectivity (USB 3.0 compatible)
• 2 mic/guitar inputs with preamps and phantom power
• 8 balanced analog inputs and outputs (TRS jack)
• XLR main outputs
• ADAT optical: 2 x in / 2 x out (up to 16 channels)
• S/PDIF, MIDI I/O, Word Clock I/O
• 24-bit conversion, up to 192 kHz sample rate
• Built-in CueMix FX mixer with DSP effects
• Standalone mode for computer-free operation

TECHNICAL SPECIFICATIONS

• Operating system: macOS / Windows
• Application area: professional studio
• Line inputs: 8
• Line outputs: 10
• Mic inputs: 2
• Phantom power: yes (+48V)
• ADAT inputs: 2
• ADAT outputs: 2
• S/PDIF input: 1 x RCA
• S/PDIF output: 1 x RCA
• Word Clock input: yes
• Word Clock output: yes
• MIDI interface: yes
• Network connections: none
• Max sample rate: 192 kHz / 24-bit
• Bus powered: no
• Power adapter included: yes
• Width: 483 mm
• Depth: 177 mm
• Height: 45 mm
• Weight: 4.19 kg
