ADAM S3H

ADAM Audio S3H 3-Way Horizontal Active Monitor – A mid-field monitor featuring dual 7″ ELE woofers (30–250 Hz), 4″ DCH midrange, and a handcrafted 2″ S-ART tweeter on an HPS waveguide. Powered by four PWM amps (2×500 W LF, 300 W MF, 50 W HF) for effortless dynamics and low distortion, with a flat 30 Hz–50 kHz response and up to 126 dB SPL (pair peak).

Built-in high-res DSP offers 2 level filters, 6-band parametric EQ, S3A emulation preset, limiter protection, AES3 I/O, and USB firmware updates. Acoustically optimized, rigid cabinet with rounded edges minimizes resonance. Remote control via S-Control (Win/Mac).

KEY FEATURES

• 3-way horizontal monitor: 2×7″ ELE woofers, 4″ DCH midrange, 2″ S-ART tweeter
• Power: 2×500 W LF, 300 W MF, 50 W HF (PWM)
• Frequency response: 30 Hz–50 kHz (–6 dB)
• Max SPL (pair peak): ≥126 dB @ 1 m
• DSP: 2 level filters, 6-band PEQ, S3A emulation, limiter protection
• Inputs: 1× XLR analog, 2× AES3 digital
• USB: firmware & S-Control remote
• HPS waveguide & acoustically braced cabinet
• 2-year warranty (+3 yrs optional registration)

TECHNICAL SPECIFICATIONS

• System: Active 3-way horizontal mid-field monitor
• Drivers:
  • 2×7″ woofer ELE
  • 4″ midrange DCH
  • 2″ tweeter S-ART with HPS waveguide
• Amplifiers: 2×500 W LF, 300 W MF, 50 W HF PWM
• Freq. Response: 30 Hz–50 kHz (–6 dB)
• Crossover: 300 Hz / 3 kHz
• Max SPL (pair peak): ≥126 dB @ 1 m
• DSP: 2 level filters, 6-band PEQ, S3A emulation, limiter
• Inputs: 1× XLR analog, 2× AES3 digital
• USB: firmware & S-Control remote
• Dimensions (W×H×D): 585 × 280 × 380 mm
• Weight: 26.6 kg
• Warranty: 2 yrs (+3 yrs registration)
