IK Multimedia UNO Synth Pro X
IK Multimedia UNO Synth Pro X is a paraphonic analog synthesizer with 3 VCOs, dual analog filters, extensive modulation and effects sections, and a 64-step sequencer. Designed for both studio work and live performance, UNO Synth Pro X combines powerful sound design features with a compact and portable format. It also integrates seamlessly with the UNO Synth Pro Editor software for macOS and Windows, unlocking additional features and enhancing the creative workflow.
The synth features three fully independent oscillators with continuously variable waveform shaping, offering PWM, sync, ring modulation, and FM capabilities. The dual-filter architecture includes a classic OTA-based multimode filter (HP/LP) and a second low-pass filter based on SSI technology with selectable 2- or 4-pole slope. Modulation options include three full ADSR envelopes and two LFOs. Built-in effects include analog overdrive and three simultaneous digital effects slots (Reverb, Delay, Modulation), with ten effects available, including chorus, univibe, five types of delay, and three reverb algorithms (Hall, Plate, Shimmer).
The powerful 64-step sequencer supports real-time recording and parameter automation across up to 48 parameters per step. An onboard arpeggiator offers 10 modes, while the Sequence Randomizer and Bassline mode make it easy to develop inspiring rhythmic and melodic patterns. The synth holds up to 256 user presets. On the rear panel, you’ll find a TRS 1/4" audio output, 1/8" mini-jack headphone and audio input, CV/Gate I/O, MIDI I/O, and USB-C port. The unit is powered via USB or the included external power supply.
KEY FEATURES
- Paraphonic analog synthesizer with digital control
- 3-voice paraphonic, monophonic, and legato modes
- 3 VCOs with PWM, sync, ring mod, and FM
- Dual analog filters: OTA multimode and SSI low-pass
- 16-slot modulation matrix
- 3 ADSR envelopes and 2 LFOs
- Analog overdrive and 3 digital effects slots: chorus/univibe, delay, reverb
- 64-step sequencer with real-time and parameter recording
- 10-mode arpeggiator and Sequence Randomizer
- 256 user preset slots
- Compatible with UNO Synth Pro Editor software (Windows/macOS)
TECHNICAL SPECIFICATIONS
- Audio output: 1/4" TRS jack
- Audio input and headphone output: 1/8" TRS mini-jack
- 2 CV/Gate inputs and 2 outputs: 1/8" TS mini-jack
- MIDI In/Out
- USB-C port (for power and data)
- Power: USB bus or included power supply
- Dimensions: 333 x 150 x 50 mm
- Weight: 0.8 kg
- Included: USB-C cable (0.6 m), power adapter, Editor/Librarian software
